2.5 inch Breech Lock Quick Joint Wireline Tool String

I.Introduction

Breech Lock Quick Joint assembly for a quick connect coupling includes a cylindrical male pin,a cylindrical sleeve-shaped female part, a rotatable key bolt, a locking bolt retainer, and a spring.The rotatable key bolt is axially arranged and central within the cylindrical sleeve-shaped female part, and has a quadrilateral locking block, a cylindrical guiding flange, and a cylindrical locking bolt having millings on opposite sides. The locking bolt retainer has a cylindrical body including a transversal hole having a radius that corresponds with an outer radius of the cylindrical locking bolt and a groove extending from the transversal hole that corresponds to the millings on the cylindrical locking bolt, a lower flange on a first side of the cylindrical body, and an upper flange located on a second side of the cylindrical body opposite to the first side, the upper flange having an inclined

surface on an upper side of the upper flange. The inclined surface of the upper flange is accessible through a hole in the cylindrical sleeve-shaped female part to unlock the manual locking assembly.

II.General Technical Parameters

Note. More customized parts are available upon request.

Welcome to contact us at any time.

◆About Baoji RuiXin Slickline Tools

Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.

◆Strict quality control system

Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.

◆Hard work, after-sales service

On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.

Quick Joint Wireline Tool String

Breech Lock Wireline Tool String

Wireline Tool String 2.5 Inch

2.5 inch Breech Lock Quick Joint Wireline Tool String Images
